All ZinAmp modules can be purchased for use in your own project. Whether you require a regulated power supply, power-amplifier or speaker protection, our extensive range of modules can augment your existing project. Try our new Module Picker to help you find what you need: Go>>>> Built using high-quality components that are easy to source. Modules available fully assembled or as bare PBCs with parts list Sort by: Project | Module Type |
||||||||
  Stereo valve pre-amplifier of exceptional quality. Warm vintage sound, very low THD and sufficient current to drive up to two power amps per channel. Requires separate power supplies for low and high voltages
Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details. Valves sold separately.
|
||||||||
 Stereo solid-state pre-amplifier of exceptional quality. Clear open sound, very low THD and sufficient current to drive up to two power amps per channel. With -/+21v rails, this module has over 40v of peak-to-peak headroom. This provides exceptional linearity, enhanced dynamics and a tube-like warmth that is never fatiguing.
Requires -/+21v power supply Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details
|
||||||||
 High Voltage Power Supply for use with ZinAmp Valve Phono and Pre Amps
Three simultaneous regulated voltages of 245v, 265v and 285v. These can be altered with component swaps. Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details. Heat-sink Mounting Plate also available
|
||||||||
 Low Voltage Power Supply for use with ZinAmp Valve Phono and Pre Amps
Two outputs of 12.6vDC and two at 7.5vDC. Used to power Heater filaments and a system startup time. Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details. Heat-sink Mounting Plate also available
|
||||||||
 Complete power supply for Valve Phono and Pre-amps. Provides 12.6v filament supply and high-voltage rail supply which is adustable between 200 and 320vDC. Twio differnt rail voltages can be supplied and these can be customised with a simple resistor swap. Powered by an 18vDC external 'wall-wart' supply. Can also be powered with a 15v AC transformer with a rectifier.
|
||||||||
 Regulated Pre Amp Supply for ZinAmp Solid State Phono and Pre Amps. Split rail supply can be set supply to +/-21v, +/-15v and +/-12v DC. can be supplied from an AC transformer or other DC Supply - like a mains adaptor. This is a truely flexible supply.
Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details
|
||||||||
 Regulating Power Supply for use with external DC supplies like desk-top, wall-wart or laptop adaptors. Filters out noise and hash from these switch-mode supplies, providing very clean DC suitable for use with solid-state phono-stages and pre-amps. Designed to work with a 30vDC supply and provide a regulated split-rail voltage of -/+12v. These will power our solid state MM and MC phono modules as well as our active crossovers. Voltages can be changed with some component swaps.
Ready-built PCB requires connectors to be purchased separately and soldered on. See datasheet for details
|
||||||||
 40VA Toroidal Transformer with dual primaries and dual secondary windings for both 12V AC and 220V AC. Specifially designed to run both 12.6V DC and 280v DC supplies for valve phono and preamp modules. Primaries can be wired in parellel for 120v AC or series for 220-240v AC
Manufactured by Airlink Transformers in the UK. CE certified and finished with three turns of Grain Oriented silicon steel to supress stray EMI. See datasheet for details
|
||||||||
Heavy duty PCB with terminals for AC transformers and connections to power supplies. Terminals are provided for an AC fuse, On/Off switch and auto-power-off switch. Additional terminals for an AC relay and two thermistors form a "soft-start" feature that protects the on/off switch and other circuitry by limiting inrush current. Can be wired for 220v or 120v DC - see datasheet. Switch nets are snubbed to prevent switch-terminal arcing/pitting
Board layout conforms with CE Low Voltage Directive in that primary and secondary AC tracks are appropriately spaced. Pre-built PCB includes screw terminal blocks as standard. Please email us if you would like different connectors
|
